Foaming car washer AY-3

AY-2 full model changes, power up! PSE certification acquisition, machine fit with Fire protection law.

特徴
  • Machine fit with "Electrical Appliance and Material Safety Law" is "Fire protection law".
  • Multi-foam car washer equipped with four liquid.
  • "Gloss ranking" of coat detergent.
  • It can be used easily at home at single-phase 100V power supply.
  • Do not choose location with compact and space-saving design.
  • High-pressure water, detergent foam, foam water repellent, coating, water repellent is freedom.
  • Car wash pole, internal filter, pressure reducing valve is such kind design.
用途
  • Gasoline stand, maintenance factory, car washing area, taxi washing area, etc…
Model AY-3
Spray pressure・Spray capacity High pressure water About 5.0Mpa
Foam -
Coat -
High pressure water About 4.9/5.0L/min(50/60Hz)
Foam About 80CC/min(When open all van)
Coat About 240CC/min(When open all van)
Washing process Water wash – Foam – Foam repellents – Water repellent – Coat
Washing hose High pressure water / Coat 3/8×13m
Foam Φ16.5×9.5×13m
Washing gun High pressure water/Coat Nozzle able to be adjusted spray corner at high pressure ,medium pressure
Foam Specilized nozzle
Water tank capacity 4L
Electric source Electric source 1 phases100V(50/60HzCommon)
Power consumption 1.0kw
Electric capacit 15A
Water supply door 15A
Water supply condition Water amount over 6L. water pressure under 1Mpa
Air condition 0.4Mpa~1.0Mpa
Dimension Height 985mm(Pole attached: 1500mm)
Width 700mm
Depth 590mm
Net weight About 95kg
Option Air hose reel, air gun, fixing bracket, antifreeze heater
Series W

In response to the trust, improve ease of use!

特徴
  • compact type can be placed in a narrow area.
  • Durability, reliability and excellent operability.
  • Equipped with high performance pump adapted to models
  • Equipped with ceramic pump
  • Free setting powerful and outstanding cleaning power - pressure
  • Vibration, quiet operation
  • Cleaning car wash operation can be speedily and light
用途
  • Petrol station, taxi, car wash of shipping company, food processing, etc.
    civil food industry, construction machinery,agricultural machines,industrial machinery and agricultural machinery, etc. animal husbandry, poultry farm,tank repair,garages and others, not chose any powerful cleaning industry.
Model W-2K-1 W-3-1 W-5-1 W-7-1 W-715-1 W-720-1 W-3C-1 W-5C-1 W-3CH-1
Spray
pressure
7 8 10 10 14.5~15 19.5~20 7 10 7
Spray
capacity
600~700 750~900 1000~1100 1400~1500 900~1000 750~850 850~1000 1000~1100 850~1000
Electric
motor(kw)
1.5 2.2 3.7 5.5 5.5 5.5 2.2 3.7 2.2
Detergent
tank
10L poly tank (manual) 10L poly tank (electromagnetic valve)
Body
Dimension
(Standard
machine)
W757×D604×H1045mm
Body
weight(Standard
machine)
About 83kg About 88kg About 100kg About 125kg About 130kg About 91kg About 105kg About 103kg
FW-1 TAMA

Small but powerful! Useful for you with especially power !

特徴
  • Compact design that can be placed in a narrow area
  • Durability, reliability and excellent operability
  • Equipped with ceramic pump
  • Powerful and exceptional cleaning power(can be changed freely pressure)
  • Vibration, quiet operation
用途
  • Taxi, shipping company,food processing wash,civil food industry,construction machinery,agricultural machines,industrial machinery and agricultural machinery, etc.
    animal husbandry,poultry farm,other tank and others, not choose any powerful cleaning industry
Model FW-1
Spray pressure 9.5Mpa
Spray capacity 800L/h
Electric motor 3 phases200V 4P 2.2kw
Body Dimension w705×D505×H506
Body weight About 60kg
Microcomputer type Car wash machine series SH

Electric heater type, hot and cold water high pressure washer

特徴
  • Wax standard equipment
  • Heater 5kw with high efficiency
  • No grease ceramic plunger pump
  • Large stainless steel hot water tank
用途
  • Coin car washing store, petrol station, parking, housing and condominiums
Model SH-7 SH-8 SH-723
Spray pressure 7.8Mpa 6.9Mpa 7.8Mpa
Spray capacity 750~900L/h 600~700L/h 750~900L/h
Electric motor AC200V 2.2kw AC200V 1.5kw AC200V 2.2kw
Car wash process System process by six courses, electronic buzzer, the indicator process Free setting car washing time
Display car washing time and cost, counter, pause function Detergent→Automactic changing to water
Wax→ Automatic changing to water
Body Dimension (W)1,107×(D)861×(H)1、347mm
Body weight 200kg
Series THW

Released washing machine 2WAY! Ideal for tensportation and SS industry

特徴
  • 2WAY So (W pumps and motors), great ideal for car washing
  • Very convenient because the free setting car wash time, price, time of using detergent
  • The long spray gun for cleaning long track(with stop function)
  • Easy to move out and install hose reel shape W
  • Be able to use detergent powder, very economical, and also make aluminum surface to be shiny!
  • Durable, long-lasting!
用途
  • Taxi company, daily wash medium-sized and heavy truck, gas station coin car wash, cold climates underbody wash, various construction machinery.
Model THW-8k THW-9k
Washing type Water wash Detergent wash Water wash Detergent wash
Spray pressure 8Mpa(80kgf/c㎡) 2Mpa(20kgf/c㎡) 10Mpa(100kgf/c㎡) 2Mpa(20kgf/c㎡)
Spray capacityL/H 750/900 210 1000/1100 210
Electric motor 200V 2.2kW 0.75kW 3.7kW 0.75kW
Body Dimension (W)1820×(D)662×(H)1560
Body weight(standard) About 180kg About 200kg
Series AWA

Besides oil, let try to use these specialized car washing machine to increase benefit, and quantity of valued customers!

特徴
  • Please refer to micro fine mist by the hot foam mousse. This is " real bubble" .
  • Depend on pole of specialized washing hose and light foam hose, so it’s easy to use.
  • It was equipped with the best equipment rely on water in pole drain structure and automatic discharge waste water function.
  • Chemical is hot water. Could be use to wash hand in the cold weather.Chemical is hot water. Could be use to wash hand in the cold weather.
  • Install air source like air compressor is an option. So you don’t need to think about the way to manage the odd air.
用途
  • Coin car wash, Petrol station, Parking, Housing and condominiums
Model AWA-1/AWA-1C
High pressure washing machine About 7.5Mpa/About 650L/h
Foam washing About 0.8/1.1Mpa/About 330/340L/h
Powerful detergent & water resistance coat About 1.0/1.7Mpa/About 235/305L/h
Wax washing About 1.0/1.7Mpa/About 235/305L/h
Electric motor 3 phases 200V、4P,2.2kw
Machine dimension (W)652×(D)562×(H)1350mm
UX-2AK

Big success at gasoline station !

特徴
  • Able to control from far distance such as car washine machine shape gate
用途
  • Gasoline station
